AW Series – Fine Pixel Pitch LED Display
The Absen AW (All-Weather) Series is a high-performance, small-pitch outdoor LED display solution designed for “near-range” viewing. Unlike traditional large billboards, the AW series is engineered for high-density applications like street furniture, light poles, and bus shelters, where viewers are closer to the screen but still require extreme weather resistance and high brightness.
| Feature | Details |
| Pixel Pitch | Available in 2.8mm and 3.9mm (Fine-pitch for outdoor) |
| Brightness | 4,500 to 5,000 nits |
| Refresh Rate | 3,840 Hz (Smooth, flicker-free visuals) |
| Ingress Protection | IP65 (Front) / IP65 (Rear) |
| Contrast Ratio | 4,000:1 to 5,000:1 for sharp image depth |
| Maintenance | Full Front & Rear Access |
| Cabinet Material | High-precision Die-cast Aluminum |
| Operating Temp | -20°C to +50°C |
Fine-Pitch Outdoor Visuals: Specifically designed with a smaller pixel pitch to provide high-definition images and clear text for pedestrians and drivers at close distances.
Ultra-High Brightness (4,500 - 5,000 nits): Ensures the display remains perfectly visible even under direct, intense sunlight, providing a much higher impact than standard outdoor LCDs.
Superior Weather Protection: Featuring an IP65/IP65 rating and a fully enclosed module design, it is built to withstand heavy rain, high humidity, dust, and extreme temperature fluctuations.
Smart Light Sensor: Equipped with automatic brightness adjustment technology that dims the screen at night to save energy and prevents light pollution, while boosting brightness during the day for maximum visibility.
Efficient Heat Dissipation: The fanless design (on certain models) or optimized airflow system ensures stable operation and a longer lifespan by preventing dust buildup and reducing noise.
Flexible Installation: Supports various mounting methods, including light pole mounting, wall mounting, and integration into kiosks or street furniture.
