NetPA U 1004 – Four Channel Power Amplifiers with Dante and DSP
Four Channel Power Amplifiers with Dante and DSP
100 Watts Per Channel
Key Features
- 100 watts rms output power per channel at 8 ohms, 4 ohms, or 70/100V
- ENERGY STAR qualified amplifier with auto-standby
- InstaWake™ exits auto-standby mode in under 100 milliseconds
- Integrated DSP with 8×8 mix matrix
- Dante Domain Manager and AES67 support ensure wide compatibility with enterprise configurations and other network audio devices
- Network monitoring and control
| Specification | Details |
|---|---|
| Power Output | 4 × 100 W RMS (into 4 Ω or 8 Ω) |
| High-Impedance Options | 70 V or 100 V models available (4 × 100 W each) |
| DSP | Integrated 8×8 mix matrix with Dante RX/TX, AES67 support |
| Thermal Design | Convection-cooled, fanless; UL 2043 plenum-rated (with adapter) |
| Standby | Auto power-down, <1 W idle, InstaWake™ <100 ms |
| Audio Metrics | THD+N ≤ 0.1 % @ 1 kHz; S/N ~100 dB; damping factor >100 (8 Ω) |
| High-Pass Filter | 80 Hz, 12 dB/oct selectable on 70 / 100 V models |
| Input/Output | 4 balanced/unbalanced line-level inputs; screw-lock speaker connectors (22 – 12 AWG) |
| Remote Control | Standby via contact closure; level control via rear recessed knobs; LED indicators front/rear |
| Physical Design | Half-rack 1U chassis, rack-mount hardware included |
| Power Supply | Global 100–240 VAC; smart low inrush design; power factor correction |
| Certifications | ENERGY STAR®, UL, RoHS; plenum rated with adapter |
| Warranty | Includes Everlast™ power supply guarantee (7‑year PSU coverage) |
The Extron NetPA U 1004 is a Dante®-enabled, four‑channel amplifier that integrates network streaming, Class D amplification with patented CDRS™ technology, and onboard DSP in a half‑rack 1U convection-cooled chassis. Designed for professional AV installations, it delivers 100 W RMS per channel into low or high impedance speaker systems. With Energy Star® certification, ultra-low idle power, and InstaWake™ (<100 ms wake from standby), this amp ensures both performance and energy efficiency.
